Wago 2003-7649: Multilevel installation terminal block; with operating slots; 2.5 mm²; N/L; Push-in CAGE CLAMP®; 2,50 mm²; gray
Beschikbaarheid:
Op voorraad
€ 1,96 (incl BTW)
Op voorraad
Wago 2003-7649: Multilevel installation terminal block; with operating slots; 2.5 mm²; N/L; Push-in CAGE CLAMP®; 2,50 mm²; gray
Electrical data
Ratings per IEC/EN
| Ratings per | IEC/EN 60947-7-1 |
| Nominal voltage (III/3) | 400V |
| Rated impulse voltage (III/3) | 6kV |
| Rated current | 24A |
| Current at conductor cross-section (max.) mm² | 32A |
| Legend (ratings) | (III / 3) ≙ Overvoltage category III / Pollution degree 3 |
Power loss
| Power loss, per pole (potential) | 0.766W |
| Rated current IN for specified power loss | 24A |
| Resistance value for specified, current-dependent power loss | 0.001Ω |
Connection data
| Connection points | 4 |
| Total number of potentials | 2 |
| Number of levels | 3 |
Connection 1
| Connection technology | Push-in CAGE CLAMP® |
| Actuation type | Operating tool |
| Connectable conductor materials | Copper |
| Nominal cross-section | 2.5 mm² |
| Solid conductor | 0.25 … 4 mm² / 22 … 12 AWG |
| Solid conductor; push-in termination | 0.75 … 4 mm² / 18 … 12 AWG |
| Fine-stranded conductor | 0.25 … 4 mm² / 22 … 12 AWG |
| Fine-stranded conductor; with insulated ferrule | 0.25 … 2.5 mm² / 22 … 14 AWG |
| Fine-stranded conductor; with ferrule; push-in termination | 1 … 2.5 mm² / 18 … 14 AWG |
| Note (conductor cross-section) | Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination. |
| Strip length | 10 … 12 mm / 0.39 … 0.47 inches |
| Wiring direction | Front-entry wiring |
Physical data
| Width | 5.2 mm / 0.205 inches |
| Height | 96 mm / 3.78 inches |
| Depth from upper-edge of DIN-rail | 42.3 mm / 1.665 inches |
Mechanical Data
| Potential marking | N/L |
| Mounting type | DIN-35 rail |
| Marking level | Center/side marking |
Material Data
| Note (material data) | Information on material specifications can be found here |
| Color | gray |
| Material group | I |
| Insulation material | Polyamide (PA66) |
| Flammability class per UL94 | V0 |
| Fire load | 0.24MJ |
| Weight | 13.6g |
Environmental requirements
| Processing temperature | -35 … +85 °C |
| Continuous operating temperature | -60 … +105 °C |
Commercial data
| Product Group | 22 (TOPJOB S) |
| eCl@ss 10.0 | 27-14-11-25 |
| eCl@ss 9.0 | 27-14-11-25 |
| ETIM 8.0 | EC001329 |
| ETIM 7.0 | EC001329 |
| PU (SPU) | 50 pcs |
| Packaging type | box |
| Country of origin | DE |
| GTIN | 4044918925624 |
| Customs tariff number | 85369010000 |
| Gewicht | 0.0136 kg |
|---|
