Bals 2194: cee stekker 125A 3P+A 230V IP67

Name: Bals 2194: cee stekker 125A 3P+A 230V IP67
Price: 122.38 EUR
Availability: InStock

Beschikbaarheid:

Levertijd +/- 5 werkdagen

€ 148,08 ~~€ 246,80~~ (incl BTW)

Levertijd +/- 5 werkdagen

Bals 2194: cee stekker 125A 3P+A 230V IP67

Plug – with TE screw terminals for harsh applications

BALS-Prd.-Nr	2194
EAN/Piece	4024941021944
Packaging Unit	5 Piece

BALS-Prd.-Nr	2194
EAN	4024941021944
Product category	TE plug
Current	125A
Number of poles	4p
Arangement of phases	3P+PE
Position of earth contact	9 h
Voltage	200 – 250V~
Frequency	50/60Hz
Protection degree	IP67
Colour code	blue RAL 5015
Colour of appliance	Pusher grey RAL 7035 Collar blue RAL 5015 Bayonet ring grey RAL 7035 Housing cover grey RAL 7035 Cable gland grey RAL 7035
Connection design	screw terminal as box terminal
Maximum conductor size	50.0 qmm
Cable entry	Cable gland
Height	273mm
Width	126mm
Depth	126mm
Material of enclosure	Polyamide
Contacts	the contact carrier is made of high temperature resistant material the contacts are brass nickel plated
